WF32-16(for liquid,powder,pulp)

• 1. Using large diameter measuring port measurement has the advantage that each measurement textured,
• such as pitting the surface of the test will be more consistent.
• 2. WF32 colorimeter can be whiteness and yellowness measurements and average measurements
• 3. large-capacity data storage space
• 4. It can be used with standard
• Product description: The colorimeter for plastic, surface treatment, painting, printing, toys, clothing, building materials, rubber, leather, glass, household appliances, printing and dyeing industry.

• Caliber 16mm version is applied on special measurements, such as the textured object, pitting, grainy surface

  or relatively large size, flexible and soft analyte.

WF32-8(for flat surface)

•

  • 1. WF32 has eight kinds of measuring light source (A, D50, D65, C, F2, F7, F11 and F12);
  • 2. six kinds of color modes (CIE1976LAB, CIEXYZ, CIELUV, HunterLAB, sRGB, white yellowness)
  • 3. eight kinds of color difference formula (△ E * ab, △ ECMC, △ EISO, △ ECIE94, △ EFCM Ⅱ, △ ELuv, △ Ehunter, △ EsRGB).
  • 4. Color simulation
  • Product description: WF colorimeter includes a series of precise, stable colorimeters,. Through accumulating years of designing and researching, it can be applicable in textile, printing and dyeing, clothing, footwear, le
           Caliber 8mm version is a general-purpose color difference meter, mostly used on flat surface considering the general method for detecting color, all walks of life habit, and the measuring caliber requirements of various materials. 8mm caliber version provides great convenience and trustworthy reliability for all industry to discuss the color technology, because of its versatility, its tiny table difference, and stability.

WF32-4(for arc cambered surface)

• 1. High-end color difference meter WF32 to fill the gaps in the field of color difference meter high repeat
• accuracy, repeatability of Δ<0.03;
• 2. High-end color difference meter WF32 with 8 standard light source, to fill gaps in the domestic color difference meter in the multiple light sources;
• 3. eight kinds of color difference formula (△ E * ab, △ ECMC, △ EISO, △ ECIE94, △ EFCM Ⅱ, △ ELuv, △ Ehunter, △ EsRGB);
• 4. It can be used with standard
•          Product description: WF32 more light, more color difference formula to meet customer demand for more measurements.
•         Caliber 4mm version is a specially designed, high performance precision colorimeter, especially suitable for small area, cambered and other special surface. It can bring great convenience for the user in the color quality detection of small devices, small parts and special type of arc.
•


  Model	WF32
  Display Mode	CIELAB、CIELCH、CIEXYZ、CIELUV、HunterLAB、sRGB
  Color Difference Formula	△E*ab、△ECMC、△EISO、△ECIE94、△EFCMⅡ、△ELuv、△Ehunter、△EsRGB
  Yellowness and Whiteness	Ganci whiteness、 ISO brightness、 YI yellowness
  Illumination Condition	CIE Recommendation：8/d
  Light Source	LED blue excitation
  Sensor	Photodiode array
  Measurement Caliber	φ4mm/φ8mm/φ16mm Alternative
  Measurement Condition	Observer：CIE 10° Standard observer Light source：A C D50 D65 F2(CWF) F7 F11(TL84) F12(U30) Contain light way：SCI SCE
  Measurement Range	L: 0 to 100
  Repeated Accuracy	△E<0.03 (take the deviation average after 30 times measuring the whiteboard)
  Table Difference	△E<0.2
  Measurement Interval	0.5 Sec.
  Average Measuring Function	Average measuring frequency: 1-32 times
  Color Simulation Function	yes
  Storage Capacity	Type sample data : 100 with testing sample data: 20000 Whiteness/yellowness data: 200
  Language Patterns	English/Simplified Chinese/Traditional Chinese
  Quality Control Software	《Color-Analysis System》 software
  Battery Charging Time	8 hrs
  Battery	Li-ion battery, 5000 times Measurement
  Lifetime of Bulb	5 years more than 1.6 million measurements
  Display Screen	TFT true color 2.8inch@(16:9) Resolution ratio:400x240
  Interface of External	USB2.0 (USB-B型)- data communication with 《color analysis system》software RS-232 (115200bps)- connected with micro printer
  Working Temperature Range	0℃-40℃（32℉-104℉）
  Storage Temperature Range	-20℃-50℃（-4℉-122℉）
  Humidity Range	Relative humidity less than 85%,without condensation
  Weight	700g
  Size	199*68*90mm
  Size of Exterior Package	400*240*340mm
  Standard Accessories	Standard whiteboard/Standard black cavity/3000mAH Li-ion battery/AC adapter/USB Data line/CD《Color analysis software》/User manual/Warranty card
  Optional Accessories	Flour measuring device/Liquid measuring device/Micro printer
